Video:
Input: 4CH AHD Standard BNC + 1CH IP (Over Network)
Output: HDMI, VGA (1280x1024), CVBS(Spot)
Recording:
AHD 5MP: 4CH 5MP Half Real-Time
50FPS (PAL)/60FPS (NTSC) Total. Up to 12/15FPS Per Channel
Resolution: 1280x720 (PAL) /1280x720 (NTSC)
AHD 2MP (1080P) & Lower:
100FPS (PAL)/120FPS (NTSC).
CVI + TVI Max. Resolution - 4CH 2MP Real-Time: 100FPS (PAL)/120FPS (NTSC)
IP channel: up to 4MP IP camera
FPS: 25(PAL) / 30(NTSC)
Playback:
4 Channel Simultaneously
Audio:
Input: 4 Channel (RCA)
Output: 1 Channel (RCA)
2 Way audio
Storage:
1 x SATA (Up to 6TB)
USB Port:
2 x USB2.0
Network:
RJ-45: 100Mbps
PTZ / Keyboard: 1 x RS485
Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
Alarm:
Input: 4 Channel
Output: 1 Channel
