Video:
16CH Standard BNC + 8CH IP (Over Network)
Output: HDMI(4K, 1920x1080), VGA (1280x1024, 1024x768), CVBS(Spot)
-
Recording:
16CH AHD/TVI/CVI/Analogue + 8CH IP
AHD:8MP Lite / 5MP / 4MP: Up to 15/12FPS Per Channel, 5MP Lite: Up to 20FPS Per Channel,
4MP Lite / 2MP / 1MP: Up to 25/30FPS Per Channel
TVI: 8MP Lite / 5MP / 4MP: Up to 15/12FPS Per Channel, 5MP Lite: Up to 20FPS Per Channel,
4MP Lite / 2MP / 1MP: Up to 25/30FPS Per Channel
CVI: 4MP: Up to 15/12FPS Per Channel, 2MP / 1MP: Up to 25/30FPS Per Channel
Analogue: 960H: Up to 30/25FPS Per Channel
IP: 8MP / 5MP / 4MP / 3MP / 2MP / 1MP: Up to 25/30FPS Per Channel
FPS: 100 (PAL) / 120 (NTSC))
-
Playback:
16 Channel Simultaneously
-
Audio:
Input: 16CH RCA (2.0 Vp-p, 1 kΩ) (+IP Cameras)
Output: 1CH RCA (2.0 Vp-p, 1 kΩ)
2 Way audio
-
Storage:
2 x SATA (Up to 8TB) + E-SATA (up to 8TB)
-
Network:
RJ-45: 1000Mbps
-
Alarm:
Input: 16CH (+IP Cameras)
Output: 4CH (+IP Cameras)
-
USB Port:
2 USB 2.0 Port
-
PTZ / Keyboard:
1 x RS485
Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
