| Camera |
|---|
|
| Image Sensor: |
| |
1/2.8" Progressive Scan CMOS |
|
| Min. Illumination: |
| |
0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
0.028Lux @ (F2.0, AGC ON) ,0 Lux with IR |
|
| Shutter time: |
| |
1/3 s to 1/100,000 s |
|
| Lens: |
| |
4mm@ F2.0, Angle of view: 85°
(6mm optional) |
|
| Lens Mount: |
| |
M12 |
|
| Day& Night: |
| |
IR cut filter with auto switch |
|
| Wide Dynamic Range: |
| |
Digital WDR |
|
| Digital noise reduction: |
| |
3D DNR |
| Compression Standard |
|---|
|
| Video Compression: |
| |
H.264/MJPEG |
|
| Video bit rate: |
| |
32Kbps~8Mbps |
|
| Dual Stream: |
| |
Yes |
| Image |
|---|
|
| Max. Image Resolution: |
| |
1920 x 1080 |
|
| Frame Rate: |
| |
50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720)
60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) |
|
| Image Settings: |
| |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
| BLC: |
| |
Yes, zone configurable |
|
| ROI: |
| |
Support |
| Network |
|---|
|
| Network Storage: |
| |
NAS (Support NFS,SMB/CIFS) |
|
| Protocols: |
| |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
|
| Security: |
| |
One-key reset, flash-prevention, dual streams, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access |
|
| System Compatibility: |
| |
ONVIF, PSIA, CGI, ISAPI |
| Interface |
|---|
|
| Communication Interface: |
| |
1 RJ45 10M / 100M Ethernet interface |
|
| On-board storage: |
| |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
|
| Reset Button: |
| |
Yes |
| Wi-Fi Specification (-W) |
|---|
|
| Wireless Standards: |
| |
IEEE802.11b, 802.11g, 802.11n |
|
| Frequency Range: |
| |
2.4 GHz ~ 2.4835 GHz |
|
| Channel Bandwidth: |
| |
20/40MHz Support |
|
| Security: |
| |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
|
| Transmission Rate: |
| |
11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps |
|
| Wireless Range: |
| |
50m(depend on environment) |
|
| Protocols: |
| |
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM
|
| General |
|---|
|
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
|
|
| Power Consumption: |
| |
MAX. 5.8W |
|
| Weather Proof: |
| |
IP67 |
|
|
| Dimensions: |
| |
70×157×62mm (2.8” × 6.1” × 2.4”) |
|
| Weight: |
| |
500g (1.1 lbs) |
