| Camera |
|---|
|
| Image Sensor: |
| |
2 MP CMOS image sensor |
|
| Signal System: |
| |
NTSC |
|
| Effective Pixels: |
| |
1920 x 1080 |
|
| Min. Illumination: |
| |
Color: 0.034 @ ƒ/2.2, B/W: 0.0034 @ ƒ/2.2, 0 with IR |
|
| Shutter Time: |
| |
1/30 s to 1/50,000 s |
|
| Lens: |
| |
2.8 mm, 3.6 mm, 6 mm optional
Angle of view: 90° (2.8 mm), 80° (3.6 mm), 55.4° (6 mm) |
|
| Lens Mount: |
| |
φ14 |
|
| Day & Night: |
| |
ICR |
|
| Synchronization: |
| |
Internal synchronization |
|
| Video Frame Rate: |
| |
1080p @ 30 fps |
|
| HD Video Output: |
| |
1 analog HD output |
|
| S/N Ratio: |
| |
More than 52 dB |
| Menu |
|---|
|
| D/N Mode: |
| |
Color/BW/EXT |
|
| White Balance: |
| |
Auto/manual |
|
| BLC: |
| |
Supported |
|
| Functions: |
| |
Digital noise reduction, mirror image |
| General |
|---|
|
| Working Temperature/Humidity: |
| |
-40° C to 60° C (-40° F to 140° F) Humidity 90% or less (non-condensing) |
|
| Power Supply: |
| |
12 VDC |
|
| Power Consumption: |
| |
Maximum 3 W |
|
| Weather Proof Ratings: |
| |
IP66 |
|
| IR Range: |
| |
65 feet |
|
| Communication: |
| |
Up-the-Coax, Protocol: HIKVISION-C |
|
| Dimensions: |
| |
Φ111 mm × 82.4 mm (Φ4.37" × 3.24") |
|
| Weight: |
| |
550 g (1.21 lbs.) |
