Thermal
|
|
Detector Type
|
Vanadium oxide uncooled focal plane detector
|
|
Effective Pixels
|
640 (H) × 512 (V)
|
|
Pixel Pitch
|
12 μm
|
|
Spectral Range
|
8 μm–14 μm
|
|
Sensitivity (NETD)
|
≤35 mK
|
|
Focal Length
|
50 mm; 75 mm; 100 mm
|
|
Field of View
|
50 mm: H: 12.4°; V: 9.9°
75 mm: H: 8.3°; V: 6.6°
100 mm: H: 6.2°; V: 5.0°
|
|
Focus Control
|
Auto; Manual
|
|
Aperture
|
50 mm: F1.0
75 mm: F1.0
100 mm: F1.1
|
|
Detection Distance①
|
50mm: Vehicle: 6,410 m (21,030.18 ft)
Human: 2,083 m (6,833.99 ft)
75mm: Vehicle: 9,615 m (31,545.28 ft)
Human: 3,125 m (10,252.62 ft)
100mm: Vehicle: 12,821 m (42,063.65 ft)
Human: 4,167 m (1,3671.26 ft)
|
|
Recognition Distance②
|
50mm: Vehicle: 1,572 m (5,157.48 ft)
Human: 536 m (1,758.53 ft)
75mm: Vehicle: 2,359 m (7,739.5 ft)
Human: 804 m (2,637.8 ft)
100mm: Vehicle: 3,145 m (10,318.24 ft)
Human: 1,071 m (3,513.78 ft)
|
|
Identification Distance③
|
50mm: Vehicle:794 m (2,604.99 ft)
Human: 268 m (879.27 ft)
75mm: Vehicle: 1,191 m (3,907.48 ft)
Human: 402 m (1318.9 ft)
100mm: Vehicle: 1,587 m (5,206.69 ft)
Human: 536 m (1,758.53 ft)
|
|
Note:
①Detection Distance: Detects objects, but cannot recognize their characteristics (objects must cover more than 3.6 pixels of the image).
②Recognition Distance: Classifies objects into general categories, such as human, vehicle (the object must cover more than 14 pixels of the image).
③Identification Distance: Classifies objects into specific categories based on their characteristics, such as engineering truck, car (the object must cover more than 28 pixels of the image).
|
|
Digital Detail Enhancement (DDE)
|
Yes
|
|
Image Stabilization
|
Electronic Image Stabilization (EIS)
|
|
Digital Zoom
|
24 levels
|
|
AGC
|
Auto; Manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
Image Flip
|
180°
|
|
Color Palettes
|
18 (white hot; black hot; fusion; rainbow; globow; ironbow1; ironbow2; sepia; color1; color2; icefire; rain; red hot; green hot; spring; summer; autumn; winter)
|
|
Visible
|
|
Image Sensor
|
1/1.8" CMOS
|
|
Max. Resolution
|
2688 (H) × 1520 (V)
|
|
Pixel
|
4 MP
|
|
Min. Illumination
|
Color: 0.005 lux
Black & white: 0.0005 lux
0 lux (IR on)
|
|
AGC
|
Auto; Manual
|
|
Noise Reduction
|
2D NR; 3D NR
|
|
S/N Ratio
|
>55 dB
|
|
White Balance
|
Auto; manual; indoor; outdoor; tracking; sodium lamp; street lamp; natural
|
|
Defog
|
Optical defog
|
|
Image Stabilization
|
Optical Image Stabilization
|
|
Electronic Shutter Speed
|
1 s–1/30,000 s (auto/manual)
|
|
BLC
|
Yes
|
|
WDR
|
Yes
|
|
HLC
|
Yes
|
|
Digital Zoom
|
Yes
|
|
Day/Night
|
Auto (ICR); Color; B/W
|
|
Image Flip
|
180°
|
|
Exposure Compensation
|
Yes
|
|
Focus Control
|
Auto; semi-auto; manual
|
|
Focal Length
|
6 mm–336 mm
|
|
Zoom Speed
|
<8.8 s
|
|
Field of View
|
H: 64.4°–1.28°
V: 38.37°–0.72°
|
|
Close Focus Distance
|
0.1 m–5 m (0.33 ft–16.4 ft)
|
|
Optical Zoom
|
56×
|
|
Aperture
|
F1.5–F5.3
|
|
IR Illumination Distance
|
150 m (492.13 ft)
|
|
IR Illuminator On/Off Control
|
Auto; Manual
|
|
Audio and Video
|
|
Video Compression
|
H.265; H.264H; H.264
|
|
Resolution
|
Thermal:
Main stream: 1280 × 1024; 1280 × 720; 640 × 512;
1280 × 1024 (default)
Sub stream: 640 × 512; 320 × 256; 640 × 512 (default)
Visible:
Main stream: 2688 × 1520; 1280 × 720; 2688 × 1520 (default)
Sub stream: 704 × 576; 352 × 288; 352 × 288 (default)
|
|
Video Frame Rate
|
Thermal (50 Hz):
Main stream: 1 fps–50 fps, 50 fps by default
Sub stream: 1 fps–25 fps, 15 fps by default
Visible (50 Hz):
Main stream: 1 fps–25 fps, 25 fps by default
Sub stream: 1 fps–25 fps, 15 fps by default
Thermal (60 Hz):
Main stream: 1 fps–60 fps, 60 fps by default
Sub stream: 1 fps–30 fps, 15 fps by default
Visible (60 Hz):
Main stream: 1 fps–30 fps, 30 fps by default
Sub stream: 1 fps–30 fps, 15 fps by default
|
|
Audio Encoding
|
G.711a; G.711mu; PCM
|
|
Image Encoding Format
|
JPEG
|
|
PTZ
|
|
Pan/Tilt Range
|
Pan: 0° to 360° endless
Tilt: –45° to +90°
|
|
Manual Control Speed
|
Pan: 0.1°/s–140°/s
Tilt: 0.1°/s–50°/s
|
|
Preset Speed
|
Pan: 0.1°/s–140°/s
Tilt: 0.1°/s–50°/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Power-off Memory
|
Yes
|
|
Privacy Masking
|
4 blocks
|
|
Idle Motion
|
Preset; auto pattern; auto tour; pan; progressive scan
|
|
Timing Task
|
Preset; auto pattern; auto tour; pan; progressive scan
|
|
Position Display
|
ON/OFF
|
|
Preset Video Freeze
|
Yes
|
|
Telephoto Speed Limit
|
Yes
|
|
Positioning Accuracy
|
± 0.1°
|
|
Wiper
|
Manual/Auto. Supports setting wiper running times, frequency, and period
|
|
3D Positioning
|
Yes
|
|
Laser Illumination (Optional)
|
|
Laser Illumination Consumption
|
4.2 ± 0.4 W
|
|
Laser Illumination Wavelength
|
850 ± 10 nm
|
|
Laser Illumination Distance
|
≥800 m (2,624.67 ft)
|
|
Angle of Laser Illuminator
|
2° to 70° adjustable
|
|
Laser Zoom Speed
|
<5 s
|
|
Brightness Setting for Laser Illumination
|
Auto; Manual
|
|
Laser Range Finder (Optional)
|
|
Laser Range Finder Wavelength
|
905 nm
|
|
Laser Range Finder Distance
|
≥1,500 m (4,921.26 ft)
|
|
Function
|
|
Two-way Audio
|
Yes
|
|
Network Protocol
|
HTTP; HTTPS; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP; Multicast; SFTP; 802.1x
|
|
Region of Interest (RoI)
|
Yes (customizable)
|
|
Storage
|
FTP; Micro SD card (optional)
|
|
Interoperability
|
ONVIF; CGI; DaHuaSDK
|
|
Browser
|
IE: IE8 and later (includs the browsers with IE kernel, such as 360 Explorer, Sougou Explorer)
Chrome: 42 and earlier
Firefox: 42 and earlier
|
|
User/Host
|
Up to 12 (total bandwidth: 64 MB)
|
|
Security
|
Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access
|
|
User Management
|
Up to 20 users; supports multi-level user permissions (2 levels): management group and user group
|
|
Malfunction Detection
|
Network disconnection detection; IP conflict detection; memory card state detection; memory space detection
|
|
PIP
|
Yes
|
|
Intelligence
|
|
Heat Detection
|
Yes. Marks the detected anomaly.
|
|
Cold/Hot Spot Trace
|
Yes
|
|
Perimeter Protection
|
Yes. Supports tripwire and intrusion.
|
|
Target Distinction
|
Human/Vehicle Classification
|
|
Target Filtering
|
Yes
|
|
Target Tracking
|
Yes
|
|
Smoke Detection
|
Yes
|
|
Boat Detection
|
Yes
|
|
Port
|
|
Analog Output
|
1 × CVBS output; BNC port
|
|
Network Port
|
1 × RJ-45 (10/100 Base-T)
|
|
Alarm Input
|
7
|
|
Alarm Output
|
2
|
|
Alarm Event
|
No SD card; low SD card space; SD card error; network disconnection; IP conflict; motion detection; video tampering; intrusion; tripwire; audio detection; defocus on thermal channel
|
|
Audio Input
|
1
|
|
Audio Output
|
1
|
|
RS-485
|
1
|
|
Power
|
|
Power Supply
|
Wide input voltage 24–57 VDC
|
|
Power Consumption
|
Basic: 39 W (illuminator off, heater off)
Max: 66 W (illuminator on, heater off); 89 W (illuminator on, heater on)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +70 °C (–40 °F to +158 °F)
|
|
Operating Humidity
|
≤95%
|
|
Storage Temperature
|
–40 °C to +70 °C (32 °F to +158 °F)
|
|
Physical Characteristics
|
|
Protection
|
IP66
|
|
Reliability
|
Surge protection: 6 kV
Air discharge: 15 kV
Contact discharge: 8 kV
|
|
Product Dimensions
|
520 mm × 266 mm × 427 mm (20.47" × 10.47" × 16.81") (L × W × H)
|
|
Packaging Dimensions
|
722 mm × 675 mm × 443 mm (28.43" × 26.57" × 17.44") (L × W × H)
|
|
Net Weight
|
≤22 kg (48.50 lb)
|
|
Gross Weight
|
≤25 kg (55.12 lb)
|
|
Installation
|
Desk mount
|
|
Power Adapter
|
Included
|
|
Lens
|
Included
|
|
PTZ Outlet
|
Side
|
|
Certification
|
|
Certifications
|
CE; FCC
|
|
Heat Detection Distance
|
|
Focal Length
|
Max. Distance
|
|
50 mm
|
3,000 m (9,842.52 ft)
|
|
75 mm
|
4,500 m (14,763.78 ft)
|
|
100 mm
|
6,000 m (19,685.04 ft)
|
|
Note:
The table displays the measured distances obtained from using the target size 2 m × 2 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.
The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more.
|
|
Perimeter Protection Distance
|
|
Focal Length
|
Distance (Human)
|
Distance (Vehicle)
|
|
50 mm
|
350 m (1,148.29 ft)
|
1,050 m (3,444.88 ft)
|
|
75 mm
|
525 m (1,722.44 ft)
|
1,575 m (5,167.32 ft)
|
|
100 mm
|
700 m (2,296.59 ft)
|
2,100 m (6,889.76 ft)
|
|
Note:
The table displays the measured distances obtained from using the target sizes
1.8 m × 0.5 m (human) and 1.4 m × 4 m (vehicle) for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.
The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more.
|
