| Camera |
|---|
|
| Image Sensor: |
| |
1/3" Progressive Scan CMOS |
|
| Min. Illumination: |
| |
Color: 0.028 @ ƒ/2.0, B/W: 0 with IR |
|
| Shutter time: |
| |
1/3 s to 1/10,000 s |
|
| Lens: |
| |
Fixed, 4 mm @ ƒ/2.0 (6 mm option)
Angle of view: 82° (4 mm), 55° (6 mm) |
|
| Lens Mount: |
| |
M12 |
|
| Day& Night: |
| |
IR cut filter with auto switch |
|
| Wide Dynamic Range: |
| |
120 dB |
|
| Digital noise reduction: |
| |
3D DNR |
| Compression Standard |
|---|
|
| Video Compression: |
| |
H.264/MJPEG/H.264+ |
|
| H.264 code profile: |
| |
Main profile |
|
| Video bit rate: |
| |
32Kbps~16Mbps |
|
| Dual Stream: |
| |
Yes |
| Image |
|---|
|
| Max. Image Resolution: |
| |
2688×1520 |
|
| Frame Rate: |
| |
20 @ 2688x1520
30 @ 1920x1080, 1280x720 |
|
| Image Settings: |
| |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
| ROI: |
| |
Yes |
|
| 3D DNR: |
| |
Supported |
| Network |
|---|
|
| Network Storage: |
| |
NAS (Support NFS,SMB/CIFS) |
|
| Alarm Trigger: |
| |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
|
| Protocols: |
| |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
|
|
| System Compatibility: |
| |
ONVIF, PSIA, CGI, ISAPI |
| General |
|---|
|
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
|
| Power Supply: |
| |
12 VDC ± 10%, PoE (802.3af) |
|
| Power Consumption: |
| |
Max. 5 W |
|
| Weather Proof: |
| |
IP67 |
|
| IR Range: |
| |
30 meters |
|
| Dimensions: |
| |
60.4 mm × 76.9 mm × 139.2 mm (2.4” × 3.0” × 5.5”) |
|
| Weight: |
| |
500g (1.1 lbs) |
