| Image Sensor: |
| |
1/3" Progressive Scan CMOS |
|
| Min. Illumination: |
| |
Color: 0.028 @ ƒ/2.0, AGC on), BW: 0 lux with IR |
|
| Shutter time: |
| |
1/3 s to 1/10,000 s |
|
| Slow shutter: |
| |
Supported |
|
| Lens: |
| |
4 mm, 6 mm options; angle of view: 83° (4 mm), 56° (6 mm) |
|
| Lens Mount: |
| |
M12 |
|
| Day& Night: |
| |
IR cut filter with auto switch |
|
| Wide Dynamic Range: |
| |
120 dB |
|
| Digital noise reduction: |
| |
3D DNR |
| Compression Standard |
|---|
|
| Video Compression: |
| |
H.264/MJPEG/H.264+ |
|
| H.264 Type: |
| |
Main profile |
|
| Video bit rate: |
| |
256 Kbps – 16 Mbps |
|
| Dual Stream: |
| |
Yes |
| Image |
|---|
|
| Max. Image Resolution: |
| |
2688×1520 |
|
| Frame Rate: |
| |
20 fps (2688 × 1520), 30 fps (1920 × 1080), (1280 × 720) |
|
| Image Settings: |
| |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
|
| BLC: |
| |
Yes, zone configurable |
|
| ROI: |
| |
Yes |
|
| 3D DNR: |
| |
Supported |
| Network |
|---|
|
| Network Storage: |
| |
NAS (Support NFS,SMB/CIFS) |
|
| Alarm Trigger: |
| |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
|
| Protocols: |
| |
TCP/IP, ICMP,H TTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
|
|
| Security: |
| |
Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
|
| System Compatibility: |
| |
ONVIF, PSIA, CGI, ISAPI |
| Interface |
|---|
|
| Communication Interface: |
| |
1 RJ45 10M / 100M Ethernet interface |
| General |
|---|
|
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
|
| Power Supply: |
| |
12 VDC ± 10%, PoE (802.3af) |
|
| Power Consumption: |
| |
Max. 7.5W |
|
| Weather Proof: |
| |
IP67 |
|
| IR Range: |
| |
50 meters |
|
| Dimensions: |
| |
299.71 mm × 86.48 mm × 85.11 mm (11.8" × 3.4" × 3.35") |
|
| Weight: |
| |
1200 g (2.65 lbs) |
